> Attendance system > SYSF203TP BIOMETRICAL

SYSF203TP BIOMETRICAL

SYSF203TP BIOMETRICAL
SYSF203TP BIOMETRICAL
SYSF203TP BIOMETRICAL
SYSF203TP BIOMETRICAL
SYSF203TP BIOMETRICAL
SYSF203TP BIOMETRICAL
Basic information:
Biometrical terminal SYSDO for attendance and access control fully equipped for recording and access control persons using facial recognition, biometric fingerprint ID chip or ID code. The reader supports TCP / IP P2P communication via Ethernet port, LCD touch screen communication port Wiegand, USB. The reader is ready and configured with the account into an online web application SYSDO where the reader can be completely configured by the user.
Internal code:E000-5705

Availability:
on order

Quantity:
Add to cart

 Attendance and access control terminal in conjunction with portal SYSDO  (comprehensive system of attendance) is the complete management of attendance and approach people anywhere in the world without having to install complicated software and configuration.

Technical parameters

 CPU
 32bit ARM
Wiegand input
 26/34 bit
 Memory
 64M Flash, 64M RAM
 Wiegand output
 26/34 bit
 Display
 2.8" TFT Color LCD, touchscreen (resistive)
Inputs
exit button, reed imput
 Optical fingerprint sesor
AES1711 500dpi, verification Facev4.0
Keyboard
 Yes, touch keyboard on LCD
FAR/FRR Face recognition
Yes
successful recognition up to 1%, unsuccessful up to 0.01%
Function keys
 Yes, touch keyboard on LCD
Camera
YES, 2 cameras for face recognition with IR illumination
 Dimensions & Weight
 174 x 87 x 142mm, weight 460g
 F/P Storage
 2K, 10K, 30K, 50K
 External reader
 Yes
Fingerprint/face capacity
 3000 fingerprints, 500 faces, 3000 codes
 Speaker
 Yes
Event memory
 500.000 events
 LED
 Yes, Two red and green
Verification speed
<= 1 sec
 Tamper
 Yes
Communication
TCP/IP
 F/P touch sensor
 Yes
 WIFI
No
 DHCP
 Yes
 USB
Yes
 Power
 9-12V DC, 1A max.
 Relay
2 /lock and bell/ 1 A / 30 V DC
 Relative humidity
 20% ~ 80% without condensation
Funkce telefonování
No
 Operating temperature
 -10 ~ 60ºC
 POE (Power of Ethement)
No
Language
 Czech/English/Chinese
 RF Card
 Emmarine 125kHz
