> LoRaWAN IoT > UR32-L04EU - Industrial Cellular Router (3G & 4G)

UR32-L04EU - Industrial Cellular Router (3G & 4G)

UR32-L04EU - Industrial Cellular Router (3G & 4G)
UR32-L04EU - Industrial Cellular Router (3G & 4G)
UR32-L04EU - Industrial Cellular Router (3G & 4G)
UR32-L04EU - Industrial Cellular Router (3G & 4G)
UR32-L04EU - Industrial Cellular Router (3G & 4G)
UR32-L04EU - Industrial Cellular Router (3G & 4G)
Basic information:
3G • 4G • Industrial Cellular Router
Order code:UR32-L04EU
Internal code:E002-0977

Availability:
on order

Quantity:
Add to cart

UR32-L04EU - Industrial Cellular Router (3G & 4G)

With a brand new look and compact size,
UR32 is specially designed to be LOW-COST and HIGHLY-EFFICIENT.
The pocket-sized design allows it to easily fit into small cabinets or machines when space is extremely limited.
Equipped with 2 fast Ethernet ports and 1 RS232 interface, UR32 can connect with diverse field assets.
With a built-in LTE CAT4 modem, it supports dual SIM backup for robust, reliable cellular communication.
Also, its rugged enclosure and wide operating temperature range (-40°C to +70°C) make it perfectly suit most
M2M applications in the harsh environment.

UR32

  • Compact and rugged design
  • PoE is optional; Wi-Fi/GPS (alternative)
  • Supports Modbus RTU/TCP
  • 1 digital input and 1 digital output
  • OpenVPN/IPsec/PPTP/L2TP/DMVPN/GRE

Specification / model comparison (UR32 vs. UR35)

UR32 UR35
Capabilities CPU 528 MHz, 32-bit ARM Cortex-A7
Flash 128 MB
Memory 128 MB DDR3
Built-in Watchdog
GPS GPS + GLONASS
Micro SD Supports micro SD card up to 128 GB
Interfaces SIM Slots 2
Ethernet Ports 2 × 10/100 Mbps 5 × 10/100 Mbps
Serial Ports 1 x RS232 (optional RS485) 1 x RS232 +1 x RS485  or 2 x RS485
DI/DO 1 × DI + 1 × DO
Antenna Connectors 2 x Cellular Connectors 1 x GPS/Wi-Fi Connector 2 x Cellular Connectors 1 x Wi-Fi Connectors 1 x GPS Connector
Network Network Protocols IPv6, PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIP v1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QoS, SNTP, Telnet, VLAN, SSH
AAA RADIUS, TACACS+, LDAP, Local Authentication
Firewall Anti-DDoS, SPI, ACL, DMZ, Port Mapping, MAC Binding
Wi-Fi (Optional) IEEE 802.11b/g/n
Serial Port Transparent (TCP Client/Server, UDP), Modbus Gateway (Modbus RTU to Modbus TCP), Modbus Master
Reliability VRRP, WAN Fail-over, Dual SIM Backup
VPN OpenVPN, IPsec, PPTP, L2TP, DMVPN, GRE
Maintenance Management Web, CLI, SMS, Watchdog, On-demand Dial Up
Multilevel Authority Multiple Levels of User Authority
Hardware Power Input 9-48 VDC
Power Output (Optional) 2 × 802.3af/at PoE PSE 4 × 802.3af/at PoE PSE
Ingress Protection IP30
Housing & Weight Metal, 271g (0.60 lb) Metal, 481g (1.06 lb)
Dimensions 108 x 90 x 26 mm (4.25 x 3.54 x 1.02 in) 135 x 100 x 45 mm (5.31 x 3.94 x 1.77 in)
Mounting Desktop, Wall or DIN Rail Mounting
Others Operating Temperature -40°C to +70°C (-40℉ to +158℉) Reduced cellular performance above 60°C
Storage Temperature -40°C to +85°C (-40℉ to +185℉)
Relative Humidity 0% to 95% (non-condensing) at 25°C/77℉
Certifications RoHS, CE, FCC, AT&T (UR32)
Frequency Band*
E
AF
AU
LTE: B1/B3/B5/B7/B8/B20/B38/B40/B41 3G: B1/B5/B8 GSM: B3/B8
LTE: B2/B4/B5/B12/B13/B14/B66/B71 3G: B2/B4/B5
LTE: B1/B2/B3/B4/B5/B7/B8/B28/B40 3G: B1/B2/B5/B8 GSM: B2/B3/B5/B8
